Comparison of the effect of different external electrodes on discharge plasma-assisted diffusion flame stabilization

To optimize the design of plasma injectors, the influence of different external electrodes on plasma-assisted flame stabilization was assessed by using a nonequilibrium plasma injector flame control setup. The electrical characteristics of the injector, flame structure parameters, flame intensity, discharge power, and cost-to-effectiveness ratio under different external electrodes (four mesh electrodes and one copper foil electrode) were analyzed using electrical and optical methods. The results show that reducing the mesh size of the external electrode leads to a decrease in breakdown voltage. Compared with a ceramic dielectric barrier-based injector, an injector with a quartz dielectric barrier produces a higher breakdown voltage under the same conditions. For the same actuation voltage, the discharge current increases as the mesh size of the external electrode decreases, and combustion is enhanced by the discharge plasma; therefore, it is better to adopt a smaller mesh hole size to realize good flame stabilization under a lower actuation voltage. However, under the studied working conditions, reducing the mesh hole size of the external electrode increases the cost-to-effectiveness ratio of plasma injector-based flame stabilization. Thus, considering the cost-to-effectiveness ratio and the weight of the injector, an external electrode with a larger mesh hole size should be chosen, which contradicts the above rule.
