Optimized analysis of ionospheric amplitude modulated heating parameters for excitation of very/extremely low frequency radiations

doi:10.1088/2058-6272/ab0bcd

Optimized analysis of ionospheric amplitude modulated heating parameters for excitation of very/extremely low frequency radiations

计量
- 文章访问数: 0188
- HTML全文浏览量: 0
- PDF下载量: 0189
出版历程
- 收稿日期: 2018-09-17

Optimized analysis of ionospheric amplitude modulated heating parameters for excitation of very/extremely low frequency radiations

¹ School of Electronic and Information Engineering, Xi’an Jiaotong University, Xi’an 710049, People’s Republic of China
² National Key Laboratory of Electromagnetic Environment, China Research Institute of Radiowave Propagation, Qingdao 266107, People’s Republic of China
³ Northwest Institute of Nuclear Technology, Xi’an 710024, People’s Republic of China

Funds: This work is supported by the Innovation Fund of China Electronics Technology Group Corporation (No. KJ1602004).

摘要

Abstract: It is now well known that amplitude modulated (AM) high frequency (HF) radio wave transmissions into the ionosphere can be used to generate very/extremely low frequency (VLF/ ELF) radio waves using the so-called ‘electrojet antenna’. Duty cycle and heating frequency are analyzed and discussed with the lower-ionosphere modulated heating model, so as to improve the radiation efficiency of VLF/ELF waves in AM ionospheric heating experiments. Based on numerical simulation, the ranges of parametric selectivity in optimal duty cycle and heating frequency ( fHF) are derived. The International Reference Ionosphere 2015 (IRI-2015) model and two-parameter model are used to predict background electron density profiles, and optimized ranges of duty cycle for different density profiles are analyzed and compared. The influences of wave polarizations on optimal duty cycle are also discussed. It is shown that intensity of the VLF/ELF equivalent radiation source ( M ) firstly rises and then falls with the increase of duty cycle. When using the IRI model, M peaks at a duty cycle of 50%, optimally ranging from 40% −70%. For the two-parameter model case, an optimal duty cycle is 40% and the optimized ranges vary from 30%−60%. Heating with an X-mode polarization is more efficient than with the O-mode case in VLF/ELF wave generation. Nevertheless, an optimal duty cycle is almost independent of HF wave polarizations. To obtain better VLF/ELF generation, optional fHF may be 0.8−0.9 times of foE for the O-mode heating and 0.75−0.85 times for the X-mode polarization case. Finally, the variations of these two parameters in different latitudes are discussed.
- amplitude modulated heating /
- parameter optimization /
- duty cycle /
- heating frequency

HTML全文

参考文献(33)

[1]	Willis S W and Davis J R 1973 J. Geophys. Res. 78 5710
[2]	Getmantsev G G et al 1974 ZhETF Pis. Red. 20 229
[3]	Stubbe P et al 1982 J. Atmos. Terr. Phys. 44 1123
[4]	Barr R, Stubbe P and Kopka H 1991 Radio Sci. 26 871
[5]	Kuo S P 1993 Radio Sci. 28 1019
[6]	Barr R and Stubbe P 1997 J. Atmos. Sol. Terr. Phys. 59 2265
[7]	Barr R, Stubbe P and Rietveld M T 1999 Ann. Geophys. 17 759
[8]	Cohen M B, Golkowski M and Inan U S 2008 Geophys. Res. Lett. 35 12
[9]	Moore R C et al 2007 J. Geophys. Res. 112 A05309
[10]	Cohen M B et al 2010 J. Geophys. Res. 115 A02302
[11]	Papadopoulos K et al 2003 Plasma Phys. Rep. 29 561
[12]	Moore R C, Inan U S and Bell T F 2006 Geophys. Res. Lett. 33 L12106
[13]	Jin G et al 2011 J. Geophys. Res. 116 A07310
[14]	Jin G et al 2012 J. Geophys. Res. 117 A11315
[15]	Cohen M B et al 2012 J. Geophys. Res. 117 A05327
[16]	Go?kowski M, Cohen M B and Moore R C 2013 J. Geophys. Res. 118 2350
[17]	Papadopoulos K et al 1990 Radio Sci. 25 1311
[18]	Cohen M B, Inan U S and Go?kowski M 2008 Geophys. Res. Lett. 35 62
[19]	Fujimaru S 2014 Optimization of beam painting for ELF/VLF wave generation at HAARP using time-of-arrival analysis PhD Thesis University of Florida, Florida, USA
[20]	Milikh G M and Papadopoulos K 2007 Geophys. Res. Lett. 34 L20804
[21]	Cohen M B and Go?kowski M 2013 J. Geophys. Res. 118 6597
[22]	Moore R C et al 2013 Phys. Rev. Lett. 111 235007
[23]	Espinosa S A and Dougherty M K 2000 Geophys. Res. Lett. 27 2785
[24]	Milikh G M et al 1999 Radiophys. Quantum Electr. 42 639
[25]	Hao S J et al 2013 Ann. Geophys. 56 A0566
[26]	Stubbe P, Kopka H and Dowden R L 1981 J. Geophys. Res. 86 9073
[27]	Tomko A A, Ferraro A J and Lee H S 1980 Radio Sci. 15 675
[28]	Rietveld M T, Kopka H and Stubbe P 1986 J. Atmos. Terr. Phys. 48 311
[29]	Moore R C 2007 ELF/VLF wave generation by modulated HF heating of the auroral electrojet PhD Thesis Stanford University, Calif, USA
[30]	Wait J R and Spies K P 1964 Characteristics of the Earthionosphere waveguide for VLF radio waves Tech. Rep. 300 Boulder Colorado: National Bureau of Standards
[31]	Thomson N R, Rodger C J and Clilverd M A 2011 J. Geophys. Res. 116 A11305
[32]	Thomson N R, Clilverd M A and McRae W M 2007 J. Geophys. Res. 112 A07304
[33]	Barr R and Stubbe P 1984 Radio Sci. 19 1111 8
