Numerical simulation and experimental verification of plasma jet development in gas gap switch

Bingbing DONG; Zhiyuan GUO; Zelin ZHANG; Tao WEN; Nianwen XIANG

doi:10.1088/2058-6272/acadc0

Plasma Science and Technology > 2023 > 25(5): 055505. > DOI: 10.1088/2058-6272/acadc0

Bingbing DONG, Zhiyuan GUO, Zelin ZHANG, Tao WEN, Nianwen XIANG. Numerical simulation and experimental verification of plasma jet development in gas gap switch[J]. Plasma Science and Technology, 2023, 25(5): 055505. DOI: 10.1088/2058-6272/acadc0

Citation:

PDF (4389 KB)

Numerical simulation and experimental verification of plasma jet development in gas gap switch

Hefei University of Technology, Hefei 230009, People's Republic of China

More Information

Corresponding author:
Bingbing DONG, E-mail: bndong@hfut.edu.cn
Received Date: September 15, 2022
Revised Date: December 20, 2022
Accepted Date: December 20, 2022
Available Online: December 05, 2023
Published Date: February 21, 2023

Graphical Abstract

Abstract

Abstract

Plasma jet triggered gas gap switch has obvious advantages in fast control switch. The development of the plasma in the ambient medium is the key factor affecting the triggering conduction of the gas switch. However, the plasma jet process and its characteristic parameters are complicated and the existing test methods cannot fully characterize its development laws. In this work, a two-dimensional transient fluid calculation model of the plasma jet process of the gas gap switch is established based on the renormalization-group k-ε turbulence equation. The results show that the characteristic parameters and morphological evolution of the plasma jet are basically consistent with the experimental results, which verifies the accuracy of the simulation model calculation. The plasma jet is a long strip with an initial velocity of 1.0 km·s^-1 and develops in both axial and radial directions. The jet velocity fluctuates significantly with axial height. As the plasma jet enters the main gap, the pressure inside the trigger cavity drops by 80%, resulting in a rapid drop in the jet velocity. When the plasma jet head interacts with the atmosphere, the two-phase fluid compresses each other, generating a forward-propelled pressure wave. The plasma jet heads flow at high velocity, a negative pressure zone is formed in the middle part of the jet, and the pressure peak decreases gradually with height. As the value of the inlet pressure increases, the characteristic parameters of the plasma jet increase. The entrainment phenomenon is evident, which leads to an increase in the pressure imbalance of the atmospheric gas medium, leading to a significant Coandǎ effect. Compared with air, the characteristic parameters of a plasma jet in SF₆ are lower, and the morphological evolution is significantly suppressed. The results of this study can provide some insight into the mechanism of action of the switch jet plasma development process.
- gas gap switch,
- plasma jet,
- k-ε turbulence model,
- numerical calculation,
- experimental verification

FullText(HTML)

Acknowledgments

This work was supported by National Natural Science Foundation of China (No. 52107142).
