Multi-layer structure formation of relativistic electron beams in plasmas

Xiaojuan WANG; Zhanghu HU; Younian WANG

doi:10.1088/2058-6272/ac4155

Plasma Science and Technology > 2022 > 24(2): 025001. > DOI: 10.1088/2058-6272/ac4155

Xiaojuan WANG, Zhanghu HU, Younian WANG. Multi-layer structure formation of relativistic electron beams in plasmas[J]. Plasma Science and Technology, 2022, 24(2): 025001. DOI: 10.1088/2058-6272/ac4155

Citation:

PDF (1316 KB)

Multi-layer structure formation of relativistic electron beams in plasmas

School of Physics, Dalian University of Technology, Dalian 116024, People's Republic of China

More Information

Author Bio:
Zhanghu HU: E-mail: zhanghu@dlut.edu.cn
Received Date: August 04, 2021
Revised Date: December 07, 2021
Accepted Date: December 07, 2021
Available Online: February 22, 2024
Published Date: January 13, 2022

Graphical Abstract

Abstract

Abstract

A two-dimensional electromagnetic particle-in-cell simulation model is proposed to study the density evolution and collective stopping of electron beams in background plasmas. We show here the formation of the multi-layer structure of the relativistic electron beam in the plasma due to the different betatron frequency from the beam front to the beam tail. Meanwhile, the nonuniformity of the longitudinal wakefield is the essential reason for the multi-layer structure formation in beam phase space. The influences of beam parameters (beam radius and transverse density profile) on the formation of the multi-layer structure and collective stopping in background plasmas are also considered.
- multi-layer structure,
- beam phase space,
- relativistic electron beam,
- plasma based beam dump,
- PIC

FullText(HTML)

Acknowledgments

This work is supported by National Natural Science Foundation of China (Nos. 12 075 046 and 11 775 042).

References (25)

References

[1]	Drake R P 2006 High-Energy-Density Physics (Berlin: Springer)
[2]	Tabak M et al 1994 Phys. Plasmas 1 1626 doi: 10.1063/1.870664
[3]	Tajima T and Dawson J M 1979 Phys. Rev. Lett. 43 267 doi: 10.1103/PhysRevLett.43.267
[4]	Chen P et al 1985 Phys. Rev. Lett. 54 693 doi: 10.1103/PhysRevLett.54.693
[5]	Joshi C, Corde S and Mori W B 2020 Phys. Plasmas 27 070602 doi: 10.1063/5.0004039
[6]	Lindstrøm C et al 2021 Phys. Rev. Lett. 126 014801 doi: 10.1103/PhysRevLett.126.014801
[7]	Roussel R et al 2020 Phys. Rev. Lett. 124 044802 doi: 10.1103/PhysRevLett.124.044802
[8]	Lu W et al 2006 Phys. Rev. Lett. 96 165002 doi: 10.1103/PhysRevLett.96.165002
[9]	Gonsalves A J et al 2019 Phys. Rev. Lett. 122 084801 doi: 10.1103/PhysRevLett.122.084801
[10]	Romeo S, Ferrario M and Rossi A R 2020 Phys. Rev. Accel. Beams 23 071301 doi: 10.1103/PhysRevAccelBeams.23.071301
[11]	Hogan M J et al 2005 Phys. Rev. Lett. 95 054802 doi: 10.1103/PhysRevLett.95.054802
[12]	Rosenzweig J B et al 1991 Phys. Rev. A 44 R6189 doi: 10.1103/PhysRevA.44.R6189
[13]	Jakobsson O et al 2019 Plasma Phys. Control. Fusion 61 124002 doi: 10.1088/1361-6587/ab4cfb
[14]	Wu H C et al 2010 Phys. Rev. Accel. Beams 13 101303 doi: 10.1103/PhysRevSTAB.13.101303
[15]	Bonatto A et al 2020 J. Phys. : Conf. Ser. 1596 012058 doi: 10.1088/1742-6596/1596/1/012058
[16]	Xia G X et al 2020 Instruments 4 10 doi: 10.3390/instruments4020010
[17]	Hogan M J 2016 Rev. Accel. Sci. Technol. 9 63 doi: 10.1142/S1793626816300036
[18]	Bonatto A et al 2015 Phys. Plasmas 22 083106 doi: 10.1063/1.4928379
[19]	Chou S et al 2016 Phys. Rev. Lett. 117 144801 doi: 10.1103/PhysRevLett.117.144801
[20]	Hu Z H and Wang Y N 2015 Plasma Phys. Control. Fusion 57 095003 doi: 10.1088/0741-3335/57/9/095003
[21]	Hu Z H, Song Y H and Wang Y N 2012 Phys. Rev. E 85 016402 doi: 10.1103/PhysRevE.85.016402
[22]	Hu Z H et al 2020 Phys. Plasmas 27 023103 doi: 10.1063/1.5126256
[23]	Lee S et al 2001 Phys. Rev. E 64 045501 doi: 10.1103/PhysRevE.64.045501
[24]	Lee S et al 2000 Phys. Rev. E 61 7014 doi: 10.1103/PhysRevE.61.7014
[25]	Shpakov V et al 2019 Phys. Rev. Lett. 122 114801 doi: 10.1103/PhysRevLett.122.114801
